Soil Testing

Showing 81–96 of 96 resultsSorted by latest

  • STSZ-ZD Full Automatic Triaxial Test Set (Ball screw rod structure)

    STSZ-ZD Full Automatic Triaxial Test Set (Ball screw rod structure)

    Feature: Controlled by singlechip, data setting of confining pressure and backpressure is by keyboard input., elavation of main frame is controlled. Main frame is driven by servo motor, and shearing rate is variable. Parameters: 1. Axial force: 0-10KN, measurement accuracy: ±1% 2. Shear rate: 0.001-2.4mm/min 3. Specimen size: Φ39.1×80mm 4. Confining pressure: 0-1Mpa 5. Backpressure:…

  • STSZ-8 80KN High Pressure Triaxial Test Set

    STSZ-8 80KN High Pressure Triaxial Test Set

    Application: determine the strength and deformation characteristics of the soil specimen. Perform unconsolidated-undrained shear test(UU), consolidated-unstrained shear test(CU) and consolidated-drained shear test(CD). Technical parameters: 1. Specimen size: Φ61.8×125,Φ101×220mm 2. Axial load:80KN 3. Lift speed range(mm/min): 0.003, 0.006, 0.008, 0.012, 0.020, 0.030, 0.040, 0.050, 0.060, 0.070, 0.080, 0.090, 0.100, 0.200, 0.300, 0.400, 0.500, 0.600, 0.700, 0.800,…

  • STSZ-2 30KN Midium Pressure Triaxial Test Set

    STSZ-2 30KN Midium Pressure Triaxial Test Set

    Application: Applied to measure the strength and deformation characteristics of the soil specimen. Perform unconsolidated undrained shear test(UU), consolidated unstrained shear test(CU) and consolidated drained shear test(CD). Technical parameters: 1. Specimen size:Φ39.1×80mm,Φ61.8×125mm 2. Axial load:30KN 3. Lift speed range(mm/min): 0.003, 0.006, 0.008, 0.012, 0.020, 0.030, 0.040, 0.050, 0.060, 0.070, 0.080, 0.090, 0.100, 0.200, 0.300, 0.400,…

  • STSZ-1Q 10KN Light-duty Triaxial Test Set

    STSZ-1Q 10KN Light-duty Triaxial Test Set

    Application: to measure soil shearing strength, thus analysizing soil stability and providing data for construction projects. Perform UU, CU and CD triaxial tests. Technical parameters: 1. Specimen size: 39.1(Dia)×80mm 2. Max. axial load: 10KN 3. Lift speed range(mm/min): 0.003,0.006,0.008, 0.012,0.020,0.030,0.040,0.050,0.060,0.070, 0.080,0.090,0.100,0.200,0.300,0.400,0.500, 0.600,0.700,0.800,0.900,1.000,3.000; 4. Max. stroke: 35mm 5. Max. confining pressure: 1Mpa 6. Max. back pressure:…

  • STSJ-5A Intelligent Electric Tetragenous Direct Shear Testing Apparatus

    STSJ-5A Intelligent Electric Tetragenous Direct Shear Testing Apparatus

    Application: This apparatus is used to test resisting shear strength of soil specimen. It usually adopts four specimens under the different vertical pressure exerted on the specimens to obtain shear stress when the specimen is destroyed. Specification: 1. Area of soil sample:30cm2 2. Lever ratio:1:12 3. Vertical Loading: 50,100,200,300,400(Kpa) 4. Max. horizontal loading: 1.2KN 5….

  • STSJ-5 Intelligent Electric Tetragenous Direct Shear Testing Apparatus

    STSJ-5 Intelligent Electric Tetragenous Direct Shear Testing Apparatus

    Application: This apparatus is used to test resisting shear strength of soil specimen. It usually adopts four specimens under the different vertical pressure exerted on the specimens to obtain shear stress when the specimen is destroyed Specification: Area of soil sample:30cm2 Lever ratio:1:12 Vertical Loading: 50,100,200,300,400(Kpa) Max. horizontal loading: 1.2KN Shear rate: 5, 2.4, 1.5,…

  • STZJY-6 Digital Electric Strain Direct Shear Apparatus

    STZJY-6 Digital Electric Strain Direct Shear Apparatus

    Application: This apparatus is used to test resisting shear strength of soil specimen. The direct shear apparatus is driven by a stepper motor and controlled by a microprocessor system, with load cell and linear electronic transducers to operate independently to perform standard or cyclic tests, programmable by keyboard input and obtaining all data concerning load,…

  • ZJ-2 Strain Direct Shear Testing Apparatus (Manual)

    ZJ-2 Strain Direct Shear Testing Apparatus (Manual)

    Application: This apparatus is used to test resisting shear strength of soil specimen. Specification: 1. Area of the soil sample:30cm2 2. Lever ratio: 1:12 3. Vertical loading: 50,100,200,300,400(Kpa) 4. Max. horizontal loading: 1.2KN 5. Shear rate: 0.02, 0.8, 2.4mm/min 6. Handwheel speed: 0.1, 4, 12mm/min 7. AC220VAC/60HZ 8. Packing measurement for EDJ-1: 880x600x1210mm, weight: 105kg…

  • EDJ-1 Electric Strain Direct Shear Testing Apparatus (Double speed) EDJ-2 Electric Strain Direct Shear Testing Apparatus (Three speed)

    EDJ-1 Electric Strain Direct Shear Testing Apparatus (Double speed) EDJ-2 Electric Strain Direct Shear Testing Apparatus (Three speed)

    Application: This apparatus is used to test resisting shear strength of soil specimen. Specification: 1. Area of the soil sample:30cm2 2. Lever ratio: 1:12 3. Vertical loading: 50,100,200,300,400(Kpa) 4. Max. horizontal loading: 1.2KN 5. Shear rate: 0.02, 0.8, 2.4mm/min 6. Handwheel speed: 0.1, 4, 12mm/min 7. AC220VAC/60HZ 8. Packing measurement for EDJ-1: 880x600x1210mm, weight: 105kg…

  • ZJ-1Q Light-duty Shear Testing Apparatus

    ZJ-1Q Light-duty Shear Testing Apparatus

    1. Testing area: 30cm2 2. Max. Vertical & horizontal loading: 1.2KN 3. Lever ratio: 1: 2 4. Rotate the hand wheel to push the axial displacement 0.2mm as per circle.

  • WG-4 Light-duty Consolidation Apparatus

    WG-4 Light-duty Consolidation Apparatus

    1.Area of sample: 30cm2 2.Pressure range:12.5-400Kpa 3.Lever ratio:1:20 4.Net weight of the equipment:20Kg Features: Small volume, light weight, suitable for using in the field.

  • STKY-200 Pore water pressure tester

    STKY-200 Pore water pressure tester

    1.Digital display: 1999 (KPs) 2.Linearity: + 0.5%FS 3.The temperature range:10 ℃ -35 ℃

  • STJCY-1 KO Consolidation Apparatus

    STJCY-1 KO Consolidation Apparatus

    Application:Include KO Consolidation Apparatus, Single type Consolidation Apparatus,Pore water pressure tester Single type Consolidation Apparatus 1. Structure: Bearing type 2. Specimen Area: 30cm2 3. Loading grade: 9 4. Pressure range: 12.5-3200Kpa 1. Size of the specimen: 61.8mm 40mm 2. Axial load: 6KN 3. Side pressure: 0Kpa1000 Kpa 4. Axial displacement: 0-10 mm 5. Working temperature:…

  • WG-1Q Full Automatic Pneumatic Consolidation Apparatus (Equip working table)

    WG-1Q Full Automatic Pneumatic Consolidation Apparatus (Equip working table)

    Application: perform consolidation tests by combining latest technique in mechnism, electronics, automation, transducer and computer, automatic load and unload, data acquisition. Features: Computer controlled, curve and test report printable Specification: 1. Precision on zero point: ±1.0Kpa 2. Loading time: within 1 second 3. Measuring range: 10mm, Resolution: 2.5um, precision: 0.2%F.S Available in three load ranges…

  • WG-1Q Full Automatic Pneumatic Consolidation Apparatus

    WG-1Q Full Automatic Pneumatic Consolidation Apparatus

    Application: perform consolidation tests by combining latest technique in mechnism, electronics, automation, transducer and computer, automatic load and unload, data acquisition. Features: Computer controlled, curve and test report printable Specification: 1. Precision on zero point: ±1.0Kpa 2. Loading time: within 1 second 3. Measuring range: 10mm, Resolution: 2.5um, precision: 0.2%F.S Available in three load ranges…

  • Triplex Consolidation Apparatus

    Triplex Consolidation Apparatus

    GDZ-2 High-pressure type Consolidation Testing Apparatus 1). Specimen area: 30cm2, 50cm2 2). Specimen number: 3 3). Pressure range: 12.5-1600kpa, 12.5-3200kpa 4). Load grade: 12.5, 25, 50, 100, 200, 300, 400, 800, 1600, 3200 WG-1B Triplex Mid-pressure Consolidation Testing Apparatus 1). Specimen area: 30cm2, 50cm2 2). Specimen number: 3 3). Pressure range: 12.5-1600kpa, 12.5-800kpa 4). Load…
